2016 - 2024 Nissan GT-R Fuse Relay Boxes Location
2016 - 2024 Nissan GT-R, has 3 fuse and relay boxes, 2 fuse relay box in the engine compartment and 1 fuse relay box in the passenger compartment.
Engine Compartment Fuse Relay Box Location:
Two fuse and relay boxes are located in the engine compartment on the passenger's side of the engine, next to the battery. The fuse relay layout diagram is on the fuse relay box cover.
Passenger Compartment Fuse Relay Box Location:
The fuse box in the passenger compartment is located on the leftt side of the driver footwell behind a cover. The fuse relay layout diagram is on the fuse relay box cover.
WARNING AND NOTES REGARDING FUSE REPLACEMENT IN THE VEHICLE:
- The vehicle is secured against rolling away.
- All electrical consumers are switched off.
- The vehicle is switched off.
- Always replace faulty fuses with specified new fuses containing the correct amperage.
- Use only fuses appeoved for Nissan with the respective fuse rating.
- When is the fuse box open, make shure that no moisture can enter the fuse box.
- When closing the fuse box, make shure that the seal of the lid is positioned correctly on the fuse box.
