2016 - 2025 Nissan LEAF Fuse Relay Boxes Location
2016 - 2025 Nissan LEAF, has 5 fuse and relay boxes, 4 fuse relay box in the engine compartment and 1 fuse relay box in the passenger compartment.
Engine Compartment Fuse Relay Box Location:
Four fuse and relay boxes are located in the engine compartment, one on the passenger's side and three on the driver's side of the engine, around the battery. Some fusible links are located on the battery.
Passenger Compartment Fuse Relay Box Location:
The fuse box in the passenger compartment is located on the driver's side, between the door and the instrument panel, behind the cover.
WARNING AND NOTES REGARDING FUSE REPLACEMENT IN THE VEHICLE:
- The vehicle is secured against rolling away.
- All electrical consumers are switched off.
- The vehicle is switched off.
- Always replace faulty fuses with specified new fuses containing the correct amperage.
- Use only fuses appeoved for Nissan with the respective fuse rating.
- When is the fuse box open, make shure that no moisture can enter the fuse box.
- When closing the fuse box, make shure that the seal of the lid is positioned correctly on the fuse box.
