2025 - 2026 Toyota 4Runner Hybrid Fuse Relay Boxes Location
2025 - 2026 Toyota 4Runner, has 4 fuse and relay boxes, 2 fuse relay box in the engine compartment,1 fuse relay box in the passenger compartment and 1 fuse relay box in luggage compartment.
Engine Compartment Fuse Relay Box Location:
The fuse relay boxes are located in the engine compartment, the fuse relay box A on the driver's side of the engine, the fuse relay box B on the passenger side of the engine. The fuse and relays layout diagram is on the fuse relay box cover. If you want a detailed layout, you can find it in the owner's manual. For example, there is a fuses in this box: WIPER (30A), TIRE INF (50A), SUB BATT (40A), RADIO (20A), HTR (50A).
Passenger Compartment Fuse Relay Box Location:
The location of the fuse relay box in the passenger compartment is on the passenger's side under the glove compartment. To access the fuse box, there is a cover just below the airbag. There are four tabs holding the cover on. To remove the cover, pull down on the outside corner and then push in on the clip to release the tab. Repeat for each of the tabs and the cover will come off.. The fuse layout diagram is on the fuse box cover. If you want a detailed layout, you can find it in the owner's manual. For example, there is a fuses in this box: STOP (10A), HAZ (10A), FUEL OPN (10A), USB NO.1 (10A).
Luggage Compartment Fuse Relay Box Location:
The location of the fuse relay box in the luggage compartment is on the driver's side, behind a cover, on the battery.
WARNING AND NOTES REGARDING FUSE REPLACEMENT IN THE VEHICLE:
- The vehicle is secured against rolling away.
- All electrical consumers are switched off.
- The vehicle is switched off.
- Always replace faulty fuses with specified new fuses containing the correct amperage.
- Use only fuses appeoved for Toyota with the respective fuse rating.
- When is the fuse box open, make shure that no moisture can enter the fuse box.
- When closing the fuse box, make shure that the seal of the lid is positioned correctly on the fuse box.
