2012 - 2017 Toyota Camry Fuse Relay Boxes Location
2012 - 2017 Toyota Camry, has 2 fuse and relay boxes, 1 fuse relay box in the engine compartment and 1 fuse box in the passenger compartment.
Engine Compartment Fuse Relay Box Location:
The location of the fuse box in the engine compartment is on the driver's side of the engine, near the battery. The fuse and relays layout diagram is on the fuse relay box cover. If you want a detailed layout, you can find it in the owner's manual or on one of the websites with diagrams and layouts of fuses and relays.
Passenger Compartment Fuse Relay Box Location:
The location of the fuse box in the passenger compartment is on the driver's side under the dashboard. The fuse layout diagram is on the fuse box cover. If you want a detailed layout, you can find it in the owner's manual or on one of the websites with diagrams and layouts of fuses and relays.
WARNING AND NOTES REGARDING FUSE REPLACEMENT IN THE VEHICLE:
- The vehicle is secured against rolling away.
- All electrical consumers are switched off.
- The vehicle is switched off.
- Always replace faulty fuses with specified new fuses containing the correct amperage.
- Use only fuses appeoved for Toyota with the respective fuse rating.
- When is the fuse box open, make shure that no moisture can enter the fuse box.
- When closing the fuse box, make shure that the seal of the lid is positioned correctly on the fuse box.
